SMD3528 P5mm full color rental indoor hanging led display screen module big wall
SMD3528 P5mm full color rental indoor hanging led display screen module big wall
SMD3528 P5mm full color rental indoor hanging led display screen module big wall
SMD3528 P5mm full color rental indoor hanging led display screen module big wall
SMD3528 P5mm full color rental indoor hanging led display screen module big wall
SMD3528 P5mm full color rental indoor hanging led display screen module big wall
SMD3528 P5mm full color rental indoor hanging led display screen module big wall
SMD3528 P5mm full color rental indoor hanging led display screen module big wall
SMD3528 P5mm full color rental indoor hanging led display screen module big wall
SMD3528 P5mm full color rental indoor hanging led display screen module big wall
SMD3528 P5mm full color rental indoor hanging led display screen module big wall
SMD3528 P5mm full color rental indoor hanging led display screen module big wall
SMD3528 P5mm full color rental indoor hanging led display screen module big wall

SMD3528 P5mm full color rental indoor hanging led display screen module big wall

Model NO.
JC-FSI-PH5MM(rental)
Price:
USD 480.00-650.00
Minimum order quantity:
1
Supply Ability:
10000 / Month
Country of Origin:
Shenzhen
Quantity:
  • Place of Origin:CN;GUA
  • Application:Indoor
  • Color:RGB
  • Panel Size:320X160mm
  • Pixel Pitch:5mm
  • Model Number:JC-FSI-PH5MM(rental)
  • Brand Name:JC
  • Usage:Indoor
  • Display Function:Video
  • Screen Dimension:640mmx640mm
  • Brightness:1500nit
  • IP rate:IP43
  • Weight:45KG/PCS
  • Panel material:Iron cabinet
  • Density:40000 pixels/sqm
  • LED type:SMD 3528
  • Warranty:2 Years
Our Services


SMD3528 P5mm full color rental indoor hanging led display screen module big wall

LED Screen Parameter



Technical DataModelPH6
Pixel Pitch6mm
Physical Density(pixels/m²)27777
LED Shape & SizeSMD 3 in 1
LED Arrangement1R1G1B
Module Size(mm)192*92
Module Resolution32*32
Drive ModeDynamic 1/16 Duty Constant Current
Brightness≥1500cd/m²
Contrast(cd/m²)≥2000:1
View Angle, 50% Brightness140°/140°
Minimum View Distance6m
Grey Scale10bits/1024levels
Color Capacity1.07billion
Maximum Power Consumption860W/m²
Ave.Power Consumption280W/m²
Operation Power SourceAC90-260V 50-60HZ
Frame Frequency60-85HZ
Refresh Rate1920HZ
Brightness Adjustment0-100% 8 levels automatic
Gamma Correction-5.0-5.0
Correction Scale Level16bits
Color Temperature5000-9300K
Brightness CorrectionPixels, Module, Cabinet Correction
Input Source SupportComposite, S-Video,Component,VGA,DVI,HDMI,SDI, HD_SDI
Control DistanceUTP CAT5E:100m;Multi-mode Fiber:50m;Single-mode Fiber:10km
Operating Temperature-40°C - 65°C
Operating Humidity10-90%RH
Operating Life Span100,000Hours
MTBF5000 Hours
Protection RatingsIP45
Out of Control Rate0.01%



Quick Details



Led module

  • Pixel:P6mm
  • Size:192mmx192mm
  • Resolution:32*32

P6-192X192_

Led cabinet

  • Size:576mmx576mm
  • Resolution:96*96
  • Type:Indoor super thin and light weight cast cabinet
  • Weight:9kg

cabinet 576x576.jpg

Led display

  • Brightness:1500nits
  • Density:27777dots per sq.m
  • IP rate:IP45
  • Scan:1/16 scan

led dispay.jpg





Latest led solutions


Company Information



JINGCAN OPTO-TEC CO.,LTDwas established in 2013, we are a professional LED media/video display exporter and manufacturer. Our company is located in Shenzhen,the focus of high end LED display technology professionals in China. Top management with  LED display experience over 80% . So far, our LED display is widely used in advertising media,sports venues and road traffic, stock exchange,financial information shows the information publicity and dislay of port terminals and airport terminals, and business propaganda in shopping and shopping centers.Exported to Germany,UK,USA, South Korea,North Korea,Thailand,Italy,Russia,Malaysia and other countries and regions. At any time, we are the best one of your reliable choice.



Company Culture

Corporate vision: led screen culture enter quality life

Corporate mission: culture is the soul, innovation is the foundation

Corporate values: being honest and unselfish


Do things to pursue excellence/  Innovation-driven development / Quality as life / Customers are always first



 Certifications

P3 LED cabinet - Certificatescertificate-01-01
