Rental lightweight P3.91 Outdoor led moving message display Led Display Panel

Model NO.
JC-FSO-PH3.91MM
Price:
USD 90.00-950.00
Minimum order quantity:
5
Supply Ability:
10000.0 / Month
Country of Origin:
Shenzhen
Quantity:
  • Usage:Outdoor
  • Tube Chip Color:FULL COLOR
  • Display Function:Graphics
  • Brightness:5500nit
  • IP rate:IP65
  • Configurations:1R1G1B
  • Gray scale per color:65536 levels
  • Life span:100000 Hours
  • Warranty:2-3 Years
  • Power Supply:Meanwell Delta G-enegry
  • Place of Origin:CN;GUA
  • Application:Outdoor
  • Color:RGB
  • Panel Size:250X250mm
  • Pixel Pitch:3.91mm
  • Model Number:JC-FSO-PH3.91MM
  • Brand Name:JC
Specification



Item
Technical Specification
Pixel
Pixel pitch: 3.91mm
Pixel configuration: 1R1G1B
Brightness: Red: 1000mcd Green: 2300mcd Blue: 600mcd
Wave length: Red: 625±2nm Green: 525±2nm Blue: 470±2nm
Module resolution: 64x64 pixels
Module
Module size: 250mmx250mm
Cabinet size: 500mm×1000mm×75mm
Cabinet
Cabinet resolution: 32768 pixels
Cabinet material: Die-casting Aluminum
Gross weight: 25kg
Module quantity:4 pcs= 2(w) x 2(h)
Power consumption : Max.:900W/m² Everage: 400W/m²
Screen
Drive method: 1/16 scanning
Brightness: 5500cd/m²
IC driver: MBI 5020
Density: 65410 pixel/m²
Whole display flatness: ≤ 1mm juncture
Best view distance: ≥ 3.91m
Viewing angle: Horizontal: 120° Vertical: 60°
Humidity(RH): ≤ 90~95%
Working temperature: from -30°C to +60°C
Working voltage: AC220V/110V±10%
Refresh frequency: 2400Hz(Zdec) ≥ 300Hz(Linsn)
Frame rate: ≥ 60Hz
Protection grade: IP65
MTBF: More than 10000hrs
Life time: 100,000 hrs
Control system
Control system: Linsn
Signal interface: DVI
Communication distance: Internet cable: ≤120m / Fiber cable: 1000m
Systems operating platforms : XP,WINDOWS(WIN95,WIN98,WIN2000)
Operating humidity
10%—95%RH
Life time
≥100,000hours
MTBF
5,000 hours
Whole Display Flatness
≤0.5mm Juncture
Frame frequency
25-60 Hz / s
Refresh rate
≥2000Hz / s
Control distance
100m (without repeater), single mode fiber:20km, multi mode fiber:
LED control system
LINSN,Nova-star,Colorlight is selectable
Operating system
Windows Xp / Windows 7 / windows 8 /8.1 / windows 10
Protection grade
IP31
Maintenance way
Rear Access

P3.91 Die-casting Magnesium Alloy LED Indoor Rental Screen 500x1000mm Cabinet 2200nit



Full Color P3.91 Indoor Led Video Wall Rental Screen Warranty

We guarantee all our displays, modules, parts for two full years. During this time, we will replace or amend all our goods for free if there is something wrong with them. We provide lifetime maintenance and charge only for the raw materials. We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory. We also provide the operation manual, software, test report and so on. Any associated CAD drawing on how to fix up the display and some other expert suggestion will be provided.

Full Color P3.91 Indoor Led Video Wall Rental  Screen Technology Training

1. We provide the technology training for free, which contains the operation training and maintenance training in the factory.
2. We will send our engineers to your country by negotiation.

Full Color P3.91 Indoor Led Video Wall Rental Screen CAD Drawing and Fixing

1. We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
2. We will send our engineers to your place if we are expected after our negotiation.

Full Color P3.91 Indoor Led Video Wall Rental Screen Additional service

We provide you the forwarding information, and some other information ,such as flight box, structure information for your reference for free.

Full Color P3.91 Indoor Led Video Wall Rental Screen Desicriptions

(1) Multiplied file formats, such as AVI, MOV, MPG, DAT, VOB are comprehensive, and also we have three display mode as VGA+VIDE and VGA. There are also interfaces for Sound signal and video signal.
(2) 4096 grade grey control system and the color is over 16.7 millions, and the brightness, contrast, saturation, chroma can be adjusted by manual and sensor, whose scope is 256 grade.
(3) Show all kinds of word, text, graph, picture, video, 2-dimention, 3-dimention cartoon and other information with your PC does synchronously.
(4) Line-Double technology is adopted for the picture adjustment.
(5) Can be connected with PC and the web net and show the content, and also can be controlled remotely via VPM+ADSL.





Cabinet Type




Hot Selling in stock




Company Information
Company Information

JINGCAN led factory’s main products areconsist of rental led display, advertising led screen, football stadiumperimeter, stage background video wall, traffic guiding display, special-shapeddisplay like curve and round, led moving light, led Par light, led modules andlaser light, etc. The outstanding features of our led products areenvironmental-friendly, energy-saving and long life-span. All of our LEDproducts have approved by CCC, CE, ROHS, FCC, ISO9001 quality certificatesauthorities. Furthermore, our LED products were exported to more than 90countries till now such as Sweden, USA, Brazil, France, Japan, Thailand, Italy,Australia, Spain and etc. Those LED products were widely used in both indoorand outdoor places like hall, hotel, exhibition room, public square, symbols,building and TV stage background and etc.




JINGCAN LED FACTORY Main LED Display Product Lines - Automatical Machines


Qualification Honor:


LED display Project around the world:




Packaging & Shipping

Packaging:

Usually, there are three tyeps of package design.

Firstly, we pack the LED display in the paper carton.

Secondly, we will pack the LED display in the flight case if  customer request for frequent movement.

Thirdly, the favorable package method is wooden case package because of its lower cost and instant usage.

packge

Note: It also could mark the brand as clients requirement.

Shipping:

We could provide air shipping, sea shipping and international Express according to clients needs.


Production Flow

Product Lines.jpg

Our Services

1. Your inquiry about our products or the price will be replied within 24 hours!
2. We provide 2 years for warranty and lifelong maintaining, you will appreciate our warm after-sale service.
3. We will delivery goods as you demand, you can choose the cheaper and more convenient way!
4. Apart from the Outdoor LED Display, Visionled also can offer you LED Pharmacy Cross Display, LED Flexible Display, Indoor LED Display, LED Gas Price Signs, Indoor/outdoor LED Signs



FAQ

1. How can I place an order?
Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time. For designing or further discussion, it is better to contact us with Skype/email /phone, in case of any delays.

2. What kind of display we provide?
We have indoor/outdoor/led curtain/mobile LED /rental LED display /LED stage/LED Dance Floor/Irregular LED display for you choose.

3. What about the lead time for order?
Always: 3-20 days, as your order quantity, sometimes we have stock, can delivery within 5 days

4.How about the warranty ?
We have two years warranty.
