Model NO.
JC-FSO-PH4MM
Price:
USD 950.00-2000.00
Minimum order quantity:
1
Supply Ability:
10000 / Month
Country of Origin:
Shenzhen
Quantity:
  • Place of Origin:CN
  • Application:Indoor
  • Color:RGB
  • Panel Size:192X192MM
  • Pixel Pitch:6MM
  • Model Number:JC-FSO-PH4MM
  • Brand Name:JC
  • Display Function:Graphics
  • Screen Dimension:512mmx512mm
  • Tube Chip Color:FULL COLOR
  • Usage:Indoor
  • Chip Color:full color
  • Brightness:1500nit
  • IP rate:IP45
  • Gray scale per color:65536 levels
  • Color:RGB 3in1 Tri Color
  • Certificate:CCC



PH6 Full color stage LED video display , SMD 3528 indoor LED screen high brightness



Quick Details:

 P6 indoor led screens
1) Relatively low cost
2) Stable capability
3) High brightness
4) Satisfactory after-sales

Product Description



1. The most cost-effective solution for stage

2.  SMD 3528 white LED, brightness over 2200 nits , very high for indoor , color is fresh

3. Wide viewing angle ,140 degree horizontally and vertically

4. Connected and controlled by PC via Lan or remote control .

5. Multiform language editions , such as English , French , Germany  and so on .

6. Small size cabinet unit , relatively light body . Easy for shipping and installing ;

7. Standard steel close cabinet , strong , firm and flat , prevent distortion during shipping and installing . Make sure the whole screen is flat  , seamless , playing good and uniform image ;

8. Indoor full color HD LED display screen video wall ;

9. SMD 3 in 1 pixel , black LED , wide viewing angle and better contrast for vivid image ;

10. Information source can be camera , video , VCD , DVD , LD , TV and so on

LED Application:



1. Culture & Tourism - playing information of landscape , interesting places , historic sites , local stories , culture , interesting manners and customs .

2. Multimedia Meeting Room -  installed as large multi-media video wall , playing the wanted video , pictures , etc . accordingly .

3. Indoor Advertising  - installed in kinds of shopping mall , super market , hotel , senior club , playing kinds of appointed ads , promotional information , etc . No matter it is video , flash , picture or text messages .

Specification



Model

P6 indoor LED video wall

Pixel pitch

6mm

Pixel density

27,777 dots /sqm

Module size(W*H)

192mm(width)*192 mm(height)

Module pixels(W*H)

32 dots *32 dots

Pixel configuration

1Red 1Green 1Blue

Drive mode

constant current driving 1/8 scan

LED lamp type

SMD3528

Cabinet size(W*H*D)

768mm*768mm

Color scale

65,536 degree

View angle(H/V)

140/120 degree

Brightness (White balance)

>2200cd/sqm.

Power consumption(one cabinet)

Max:300W / cabinet , Average: 100W / cabinet

Operating Voltage

90-264 VAC, 47-63Hz

Net weight

12Kg / cabinet

Operating temperature

-30°C----+60°C

Operating humidity

10%—95%RH

Life time

≥100,000hours

MTBF

5,000 hours

Whole Display Flatness

≤0.5mm Juncture

Frame frequency

25-60 Hz/s

Refresh rate

≥2000Hz /s

Control distance

100m (without repeater),

LED control system

LINSN,Dbstar,Nova-star,ZDEC,Colorlight is selectable

Operating system

Windows Xp / Windows 7 / windows 8 /8.1 / windows 10

Protection grade

IP31

Maintenance way

Rear  Access

Accepting signal with video processor

PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI



Detailed Images






Production Flow

Product Lines.jpg







Our Services

1. Pre-sales service:

a) Our company can arrange professionals to conduct site installation and debugging in strict accordance with the requirements of the schemes and the original manual. If there is any special requirement, it is necessary to make changes of part installation scheme, we will coordinate with users. Our company can ensure the consistence of completion time and contracted time.  Any problems caused by natural factors or man-made, we will discuss with client to find solutions.
b) Our company can train the users based on the manual.  The training include system use, system maintenance and equipment protection.



2. After-sales service:

a) Service principles: response in time, solve problems as soon as possible and ensure the use.
b) Service period: In the Maintenance period of the LED screen body, free of all maintenance charges; After Maintenance period, only charge the material costs fees free of manual work fees.
c) Service scope: If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips etc.
d) Under normal use and storage, Our Company will be responsible for the equipments.



Repair Service for LED Display Lifelong time



how to repair outdoor led module.jpg

Packaging & Shipping

Usually, there are three tyeps of package design.



Firstly, we pack the LED display in the paper carton.

Module Package 01



Secondly, we will pack the LED display in the flight case if  customer request for frequent movement.

package







Thirdly, the favorable package method is wooden case package because of its lower cost and instant usage.



wooden case 01.jpg
