HD 3MM Pixel LED Display screen
HD 3MM Pixel LED Display screen
HD 3MM Pixel LED Display screen
HD 3MM Pixel LED Display screen
HD 3MM Pixel LED Display screen
HD 3MM Pixel LED Display screen
HD 3MM Pixel LED Display screen
HD 3MM Pixel LED Display screen
HD 3MM Pixel LED Display screen
HD 3MM Pixel LED Display screen
HD 3MM Pixel LED Display screen

HD 3MM Pixel LED Display screen

Model NO.
USD 950.00-1,100.00
Minimum order quantity:
Supply Ability:
10000 / Month
Country of Origin:
  • Place of Origin:CN;GUA
  • Usage:Indoor
  • Tube Chip Color:FULL COLOR
  • Display Function:Graphics
  • Pixels:p3 full color indoor led large screen display
  • Brand Name:JC
  • Model Number:JC-FSO-PH3MM
  • Screen Dimension:576mmx576mm
  • Chip Color:full color
  • Brightness:1500nit
  • Panel material:Al-frame cabinet
  • IP rate:IP45
  • Weight:3~5KG/PCS
  • Configurations:1R1G
  • Density:17222 pixels/sqm
  • Gray scale per color:65536 levels
  • Colors:281 trillion billion
  • Type:p3 full color indoor curve led display screen

P3 Die - Casting Aluminum SMD LED Display Rental 576mmx576mm With Linsn / Nova Software


Trade Terms


1.Payment: T/T 35% as deposits before production, T/T 65% balance before delivery

2.Shipping freight are quoted under your requests

3.Shipping port: Shenzhen, Mainland China

4.MOQ:1sqm p7.62 one line english led message signboard

5.Delivery time: 10-15days after receive pre-payment



Feature and Advantage


1.High brightness Contrast:4000:1, which is a very high level to ensure a vivid image of our LED display screen system

2. First-class LED chip: Supplied by Cree & other high strictly selected LED chip to ensure the long lift-time and high brightness of our LED display screen system

3.Clear vivid image quality even in direct, full-on sunlight to ensure you attracts more audience to get short ROIof  your LED display screen's investment.

4.Long-term Brightness:More 7000-nit brightness(for outdoor full color)(2000 nits brightness for indoor full color)capacity throughout product lifetime of the LED display screen.

5.Easy Installation & Using: easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system

6.Convenient Servicing: Front and rear cabinet access make the maintance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.


Our service



1.Your inquiry related to our products or price will be replied in 24hrs

2.OEM&ODM,any your customized lightings we can help you to design and put into product

3.Distributoership are offered for your unique design and some our current models

4.Protection of your sales area,ideas of design and all your private information

5.Top Quality+Reasonable Price+Responsible After Service=Successful & Win

6. Export countries :  Peru,  Mexico, Colombia, Turkey, US, UK, etc.


LED Screen Parameter


Technical DataModelPH3
Pixel Pitch3mm
Physical Density(pixels/m²)111111
LED Shape & SizeSMD 3 in 1
LED Arrangement1R1G1B
Module Size(mm)192×96
Module Resolution64*32
Drive ModeDynamic 1/8 Duty Constant Current
View Angle, 50% Brightness140°/140°
Minimum View Distance3m
Grey Scale10bits/1024levels
Color Capacity1.07billion
Maximum Power Consumption860W/m²
Ave.Power Consumption280W/m²
Operation Power SourceAC90-260V 50-60HZ
Frame Frequency60-85HZ
Refresh Rate240-1000HZ
Brightness Adjustment0-100% 8 levels automatic
Gamma Correction-5.0-5.0
Correction Scale Level16bits
Color Temperature5000-9300K
Brightness CorrectionPixels, Module, Cabinet Correction
Input Source SupportComposite, S-Video,Component,VGA,DVI,HDMI,SDI, HD_SDI
Control DistanceUTP CAT5E:100m;Multi-mode Fiber:50m;Single-mode Fiber:10km
Operating Temperature-40°C - 65°C
Operating Humidity10-90%RH
Operating Life Span100,000Hours
MTBF5000 Hours
Protection RatingsIP31
Out of Control Rate0.01%
