Model NO.
JC-FSO-PH6.67MM
Price:
USD 58.00-79.00
Minimum order quantity:
1
Supply Ability:
10000 / Month
Country of Origin:
Shenzhen
Quantity:
  • Place of Origin:CN;GUA
  • Application:Outdoor
  • Color:Full color
  • Panel Size:320x320mm
  • Pixel Pitch:6.67
  • Model Number:JC-FSO-PH6.67MM
  • Brand Name:JC
  • Usage:OUTDOOR
  • Display Function:Video
  • Tube Chip Color:1R1G1B
  • Pixels:6.67
  • Screen Dimension:960mmx960mm/960x640mm
  • Panel material:Front service iron cabinet
  • IP rate:IP68
  • Weight:37KG/sqm
  • Configurations:1R1G1B
  • Cabinet size:960*960mm
Quick Details

 P6.67 Outdoor waterproof  led module with 320x320mm


P6.67 outdoor fanless without back cover front service led iron cabinet

P6.67 1050USDEXW.png


P6.67 outdoor led display customized size

LED WALL_3.jpg



Product Description
P6.67 Outdoor Led Module
Pixel pitch6.67mm
LED configurationSMD3535
Module size320mmWx320mmHx16mmD
Pixel density(sq.m)20736dots

Pixel resolution

48x48
Port typeHUB75
Brightness800-6500nits
Pixel configuration1R1G1B
Drive typeconstant drive
Scan Mode1/5 scan





P6.67 Outdoor Led Display
Cabinet size
960mmWx960mmHx120mmD
Quantity of module9pcs
Power supply5V 60A 300W
Pixel per cabinet
144x144

Weight

37kgs
Best viewing distance>6.67m
Best viewing angle160 degrees(H)x140 degrees(V)
Pixel configurationstorage:-35℃-+85℃ [-31℉-+185℉]
Working Temperature
-20℃-+60℃ [-4℉-+140℉]
Operation humidity
20%-90%
Protection classificationIP68



Certifications





Packaging & Shipping

Packing: Anti-shaking wooden cabinet/Air flight case/strong carton

Shipping port: Shenzhen, China

Shipping way:Air;Express;Ocean;Land Transportation

Delivery time: 7-15 working days after confirm receipt  payment in advance.

Long working life: In the Maintenance period, free of all maintenance charge.After maintenance period only charge the material costs fees.
